Sensor-switched LED indoor light - Professional Line

RS PRO A10 SC

Sensor-switched LED indoor light - Professional Line

RS PRO A10 SC Neutral white white

EAN 4007841088309
  • Ideal for demanding environments such as pergolas or similar applications
  • Non-visible high-frequency sensor with ø8 m range, 4000 K, 1172 lm, 10,7 W, 109,5 lm/W
  • Robust aluminium housing with high impact resistance IK10 and protection class IP54
  • Simple networking via Bluetooth Mesh Connect and commissioning via STEINEL Connect app
  • Benefits of the Connected Lighting System and cross-range networking possible
  • With plug-in terminals for easy installation
  • You're watching:
    Connected Lighting in the application.
  •
    Elegant and robust.
Connected Lighting in the application.

The combination of sensor technology, efficient LED light, networking and intelligent control ensures needs-based switching and creates greater convenience and safety for users. The system is also unbeatably easy to install thanks to tool-free commissioning via the Steinel Connect app. A 5-year manufacturer's guarantee, BEG eligibility and savings of up to 95% on electricity and maintenance costs round off the benefits for everyone involved.

Technical Specifications
Quick overview
Download datasheet
Application, place
Indoors
Installation
Surface wiring
With motion detector
Yes
Interconnection via
Bluetooth Mesh
Output
10,7 W
Luminous flux total product
1172 lm
Colour temperature
4000 K
Article number
088309
PU1, net weight
0,835 kg
36 years (Ø 4,5h / day)
Settings via App
4000K neutral white
high frequency sensor 360°
max. 8 m
2 - 2000 lux
IP54
shock proof IK10
Light source not exchangeable

General

Dimensions (Ø x H)
193 x 69 mm
With lamp
Yes, STEINEL LED system
With motion detector
Yes
Manufacturer's Warranty
5 years
Settings via
Bluetooth, App
With remote control
No
Version
Neutral white white
PU1, EAN
4007841088309
Application, place
Indoors
Application, room
corridor / aisle, function room / ancillary room, warehouse, kitchenette, stairwell, changing room, WC / washroom
Colour
white

Fixation/ mounting

includes sheet of self-adhesive numbers
No
Installation site
ceiling, wall
Installation
Surface wiring, Ceiling

Housing

Impact resistance
IK10
IP-rating
IP54
Protection class
II
Ambient temperature
from -20 up to 40 °C
Housing material
Aluminium
Cover material
PC, opal
IP-rating, ceiling
IP54

Electrical equipement

Mains power supply
220 – 240 V / 50 – 60 Hz
Output
10,7 W

Sensor technology

Mounting height max.
4,00 m
HF-system
5,8 GHz
Slave modeselectable
Yes
Detection
also through glass, wood and stud walls
Capability of masking out individual segments
No
Electronic scalability
Yes
Mechanical scalability
No
Reach, radial
Ø 8 m (50 m²)
Reach, tangential
Ø 8 m (50 m²)
Detection angle
360 °

Luminaire

Photo-cell controller
Yes
Luminous flux total product
1172 lm
Total product efficiency
109,5 lm/W
Colour temperature
4000 K
Colour variation LED
SDCM3
Lamp
LED cannot be replaced
Base
without
LED cooling system
Passive Thermo Control
Soft light start
Yes
Continuous light
selectable
Lifetime LED according to IEC-62717 (L70)
> 60.000 Std.
Colour Rendering Index CRI
= 80

General information

Article number
088309
European Article Number (EAN)
4007841088309
Transmitter power
< 1 mW
Basic light level function in per cent
0 – 100 %
Angle of aperture
160 °

Functions

Functions
Selecting programmed lighting scenarios, Motions sensor, DIM function, Adjustable fade time when switching on and off, Semi-/fully automatic, Neighbouring group function, Encrypted communication, Timer
Twilight setting
2 – 2000 lx
Time setting
10 s – 60 Min.
Basic light level function
Yes
Basic light level function time
1-60 min
Main light adjustable
0 - 100 %
Twilight setting TEACH
Yes

Connection

Interconnection
Yes
Type of interconnection
Master/master
Interconnection via
Bluetooth Mesh

General information

Product category
Sensor-switched LED indoor light
Downloads
Safety and Warning Instructions
1. Important product information
Please read carefully and keep in a safe place. – Under copyright. Reproduction either in whole or in part only with our consent.

2. General safety precautions
Risk of electric shock! 230 V means danger to life! Disconnect the power supply before attempting any work on the unit. During installation, the electric power cable being connected must not be live. Therefore, switch off the power first and use a voltage tester to make sure the wiring is off-circuit. Installing the sensor-switched light involves work on the mains voltage supply. This work must therefore be carried out professionally in accordance with national wiring regulations and electrical operating conditions. (e.g. DE - VDE 0100, AT - ÖVE / ÖNORM E8001-1, CH - SEV 1000) Only use genuine replacement parts. Repairs may only be made by specialist workshops.

3. Proper use
Sensor-switched wall/ceiling light with active motion detector. Limited suitability for outdoor use as a result of detection sensitivity.

4. Electrical Connection
Important: the light source of this luminaire cannot be replaced. If the light source needs to be replaced (e.g. at the end of its service life), the complete luminaire must be replaced. Connection to a dimmer will result in damage to the sensor-switched light. Note: do not make direct contact with the LED.

5. Installation
Check all components for damage. Do not use the product if it is damaged. When installing the unit, make sure the installation site is not subject to vibration. Select an appropriate mounting location, taking the reach and motion detection into consideration.

6. Cleaning and Maintenance
The unit requires no maintenance. Hazard from electrical power. Contact between water and live parts can result in electrical shock, burns or death. Only clean unit in a dry state. Risk of damage to property! Using the wrong detergent can damage the light. Clean unit with a moist cloth without detergent.

7. Disposal
Electrical and electronic equipment, accessories and packaging must be recycled in an environmentally compatible manner. Do not dispose of electrical and electronic equipment as domestic waste. EU countries only: Under the current European Directive on Waste Electrical and Electronic Equipment and its implementation in national law, electrical and electronic equipment no longer suitable for use must be collected separately and recycled in an environmentally compatible manner.
Manufacturer information
Manufacturer
STEINEL GmbH
Dieselstraße 80-84
33442 Herzebrock-Clarholz
Germany
