Presence detector - Professional Line

IR Quattro HD-2 24m

Presence detector - Professional Line

IR Quattro HD-2 24m KNX - concealed white

EAN 4007841064846
  • Passive infrared presence detector with square 360° detection
  • 5.200 switching zones for the finest detection
  • Offers the largest detection range in our IR range
  • 4 pyro sensors individually de-/activatable
  • Sensitivity digitally adjustable
  • Measures presence and brightness
  • Temperature and humidity measurement with IP, KNX and DALI-2 IPD
  • Setting and networking via Bluetooth
  • Ideal for open-plan offices and classrooms
  • You're watching:
    Sensors integrated in the Bluetooth network.
  •
    Among our infrared presence detectors, the one with the largest detection range.
Sensors integrated in the Bluetooth network.

STEINEL sensors show how to use energy intelligently. The technologically innovative and pioneering products maximise energy efficiency. Integrated into the Connected Lighting System, the maximum potential of building automation can be utilised.

Technical Specifications
Quick overview
Download datasheet
Application, place
Indoors
Installation
Concealed wiring
Detection angle
360 °
Reach, tangential
24 x 24 m (576 m²)
Mounting height max.
10,00 m
Interconnection via
KNX bus, Bluetooth Mesh
Version
KNX - concealed white
Article number
064846
PU1, net weight
0,135 kg
67 103 103
infrared sensor
ideal 2,5 - 10 m
2 - 2000 lux
5 sec - 60 min
KNX
Settings via App
temperature
air humidity
movement

General

Dimensions (L x W x H)
67 x 103 x 103 mm
Manufacturer's Warranty
5 years
Settings via
Bus, ETS software, App, Potentiometers, Bluetooth Mesh
With remote control
No
Version
KNX - concealed white
PU1, EAN
4007841064846
Type
Presence detector
Application, place
Indoors
Application, room
lecture hall, classroom, open-plan office, high-bay warehouse, production facilities, conference room / meeting room, duty room, recreation room, changing room, reception / lobby, sports hall, multi-storey / underground car park, dining hall / staff restaurant, Indoors
Colour
white
Colour, RAL
9003

Fixation/ mounting

Includes corner wall mount
No
Installation site
ceiling
Installation
Ceiling, Concealed wiring

Housing

IP-rating
IP20
Ambient temperature
from 0 up to 40 °C
Material
Plastic

Electrical equipement

Mains power supply
30 V
Power consumption
0,3 W
Power supply, detail
KNX bus
With bus coupling
Yes

General information

Article number
064846
European Article Number (EAN)
4007841064846
Detection angle
360 °
Angle of aperture
160 °
Rated current
10 mA

Sensor technology

Technology, sensors
Light sensor, passive infrared, Air humidity, Temperature
Mounting height
2,50 – 10,00 m
Mounting height max.
10,00 m
Optimum mounting height
2,8 m
Sneak-by guard
Yes
Capability of masking out individual segments
Yes
Electronic scalability
Yes
Mechanical scalability
Yes
Reach, radial
9 x 9 m (81 m²)
Reach, tangential
24 x 24 m (576 m²)
Reach, presence
9 x 9 m (81 m²)

Functions

Twilight setting
2 – 2000 lx
Time setting
10 s – 1092 Min.
Basic light level function
Yes
Main light adjustable
0 - 100 %
Twilight setting TEACH
Yes
Constant-lighting control
Yes
KNX functions
Comfort, Photo-cell controller, Individual pyro evaluation, Basic light level function, Light level, HVAC output, Constant-lighting control, Light output 4x, Humidity output, Presence output, Day / night function, Dewpoint, Temperature output, Logic gate

Connection

Interconnection
Yes
Interconnection via
KNX bus, Bluetooth Mesh

General information

KNX Medium
TP 256
KNX Secure
No
Product category
Presence detector
Product Details
  • Image
    UV-resistant plastic
Downloads
Safety and Warning Instructions
1. Important product information
Please read carefully and keep in a safe place. – Under copyright. Reproduction either in whole or in part only with our consent.

2. General safety precautions
This product may only be installed by a qualified electrician in accordance with national wiring regulations as defined in VDE 0829-1 (DIN EN 50090-1). This product may never be connected to mains voltage (230 V AC) as this would present a risk of serious injury or damage to property. It is only intended for connection to an extra-low voltage power supply. Only use genuine replacement parts. Repairs may only be made by specialist workshops.

3. Proper use
The use for which the sensor version is intended is described in the relevant general operating instructions. The general operating instructions can be opened by using the QR code from the Quick Start provided.

4. Installation
Check all components for damage. Do not use the product if it is damaged. When installing the product, make sure the installation site is not subject to vibration. Select an appropriate mounting location, taking the reach and motion detection into consideration.

5. Cleaning and Maintenance
The product requires no maintenance. Hazard from electrical power. Contact between water and live parts can result in electrical shock, burns or death. Only clean the product in a dry state. Risk of damage to property! Using the wrong detergent can damage the product. Clean product with a moist cloth without detergent.

6. Disposal
Electrical and electronic equipment, accessories and packaging must be recycled in an environmentally compatible manner. Do not dispose of electrical and electronic equipment as domestic waste. EU countries only: Under the current European Directive on Waste Electrical and Electronic Equipment and its implementation in national law, electrical and electronic equipment no longer suitable for use must be collected separately and recycled in an environmentally compatible manner.1. **Important product information**
Please read carefully and keep in a safe place. – Under copyright. Reproduction either in whole or in part only with our consent.

2. **General safety precautions**
This product may only be installed by a qualified electrician in accordance with national wiring regulations as defined in VDE 0829-1 (DIN EN 50090-1). This product may never be connected to mains voltage (230 V AC) as this would present a risk of serious injury or damage to property. It is only intended for connection to an extra-low voltage power supply. Only use genuine replacement parts. Repairs may only be made by specialist workshops.

3. **Proper use**
The use for which the sensor version is intended is described in the relevant general operating instructions. The general operating instructions can be opened by using the QR code from the Quick Start provided.

4. **Installation**
Check all components for damage. Do not use the product if it is damaged. When installing the product, make sure the installation site is not subject to vibration. Select an appropriate mounting location, taking the reach and motion detection into consideration.

5. **Cleaning and Maintenance**
The product requires no maintenance. Hazard from electrical power. Contact between water and live parts can result in electrical shock, burns or death. Only clean the product in a dry state. Risk of damage to property! Using the wrong detergent can damage the product. Clean product with a moist cloth without detergent.

6. **Disposal**
Electrical and electronic equipment, accessories and packaging must be recycled in an environmentally compatible manner. Do not dispose of electrical and electronic equipment as domestic waste. EU countries only: Under the current European Directive on Waste Electrical and Electronic Equipment and its implementation in national law, electrical and electronic equipment no longer suitable for use must be collected separately and recycled in an environmentally compatible manner.
